Description

12V underfloor insulation Mi-Blcok Footfall Sound Insulation with Vapor Barrier 5mm. sold by the metre,  width 1.18m . The Mi-Block insulation underlayment, thanks to integrated vapor barrier (Aqua Stop), high pressure resistance and punctual leveling features, perfect for electric underfloor heating.

The heating film underlay thus serves as additional insulation and allows the connection cables of the heating film to be accommodated. Simply cut out the underlay where you need to make space for the connection cable.

The Mi-Block (heating film underlay) meets the requirements of the EPLF and MMFA (Group 1).

Scope of Application
for floating installation of
laminate
parquet
Design / vinyl floors on HDF carrier

Features
robust underlay
great warmth reflection through aluminium layer
sound proof
dampf proof

Specifications
Material thickness: 5mm
Material: extruded polystyrene foam
Punctual compensation: up to 4mm
Compressive strength: 90kPa
Permanent compressive strength: 25kPa
Dynamic compressive strength: 250,000 cycles
Shock resistance: 140cm
Water vapor diffusion resistance: 100m
Thermal resistance: ~ 0.15m²K / W
Impact sound reduction: 22dB
Dimensions 1 m x 1.18m

Processing
1. Clean the surface
2. Lay out the Mi-Block (heating film pad)
3. Remove the protective strips from the double-sided adhesive tape and glue the overlaps of the butt joints
4. Lay out and wire the Mi-Heat heating foil
5. Cut or cut out areas for the connection cables and connection points of the heating foil
6. Cover the Mi-Heat heater with the optionally available PE vapor barrier
7. Finally, the floor covering can be laid floating
